STRS6525 Datasheet - Allegro

STRS6525 - OFF-LINE SWITCHING REGULATOR WITH POWER MOSFET OUTPUT

STR-S6525 OFF-LINE SWITCHING REGULATOR WITH POWER MOSFET OUTPUT DRAIN 1 OSC.

FAULT LATCH Data Sheet 28102.11 SOURCE 2 R COMMON 3 S The STR-S6525 is specifically designed to meet the requirement for increased integration and reliability in off-line flyback converters operating in a constant OFF-time mode.

The device incorporates the primary control and drive circuit with a discrete avalanche-rated highvoltage power MOSFET.

Crucial system parameters such as maximum ON time and OFF

STRS6525 Features

* s Constant OFF-Time Converter Operating Mode s Avalanche-Rated Power MOSFET Switch s Pulse-by-Pulse Current Limiting s Latched Over-Voltage and Thermal Protection s Maximum ON Time and OFF Time Set During Manufacture s Internal Under-Voltage Lockout with Hysteresis s Over-Molded SIP with Integral I

STRS6525_Allegro.pdf

Preview of STRS6525 PDF
STRS6525 Datasheet Preview Page 2 STRS6525 Datasheet Preview Page 3

Datasheet Details

Part number:

STRS6525

Manufacturer:

Allegro

File Size:

91.54 KB

Description:

Off-line switching regulator with power mosfet output.
