AO3700 Datasheet (Alpha & Omega Semiconductors)

AO3700, N-Channel FET

The AO3700 uses advanced trench technology to provide excellent R DS(ON) and low gate charge.

A Schottky diode is provided to facilitate the implementation of a bidirectional blocking switch, or for DC-DC conversion applications.

Standard Product AO3700 is Pb-free (meets ROHS & Sony 259 specificatio

AO3700 Features

* VDS (V) = 30V ID = 3.3A (V GS = 10V) RDS(ON) < 65m Ω (VGS = 10V) RDS(ON) < 75m Ω (VGS = 4.5V) RDS(ON) < 160m Ω (VGS = 2.5V) SCHOTTKY VDS (V) = 20V, I F = 1A, VF
