AO3703 Datasheet - Alpha & Omega Semiconductors

P-Channel FET

AO3703 Features

* VDS (V) = -20V ID = -2.7 A (VGS = -10V) RDS(ON) < 97m Ω (VGS = -4.5V) RDS(ON) < 130m Ω (VGS = -2.5V) RDS(ON) < 190m Ω (VGS = -1.8V) SCHOTTKY VDS (V) = 20V, I F = 1A, VF

AO3703 General Description

The AO3703 uses advanced trench technology to provide excellent R DS(ON) and low gate charge. A Schottky diode is provided to facilitate the implementation of a bidirectional blocking switch, or for DC-DC conversion applications. Standard Product AO3703 is Pb-free (meets ROHS & Sony 259 specificatio.

AO3703 Datasheet (133.83 KB)

AO3703 Datasheet Preview — Preview of AO3703 PDF

Datasheet Details

Part number:

AO3703

Manufacturer:

Alpha & Omega Semiconductors

File Size:

133.83 KB

Description:

P-channel fet.
