Part number: SMA-B500LB
Manufacturer: American Opto Plus LED
File Size: 464.86KB
Download: 📄 Datasheet
Description: LED Display
* Bar graph display.
* Excellent character appearance.
* Wide viewing angle.
* Gray face, white bar.
* Super Thin SMD Type.
* RoHS compliant, Pb F.
The SMA-B500LB G/W is a rectangular bar graph display. This device utilizes Super Bright Blue LED chip which are made from InGaN on a transparent GaN substrate. The display has Gray face and white bars.
* DEVICE
PART NO Super Bright Blue SMA-B50.
