AD6630 Datasheet, Clamping, Analog Devices

AD6630 Features

• Clamping 24 dB Gain 4 dB Noise Figure Easy Match to SAW Filters Output Limiter Adjustable +8.5 dBm to +12 dBm 700 MHz Bandwidth 10 V Single or Dual 5 V Power Supply 300 mW Power Dissipation APPL

PDF File Details

Part number:

AD6630

Manufacturer:

Analog Devices ↗

File Size:

129.00kb

Download:

📄 Datasheet

Description:

Differential/ low noise if gain block with output clamping. The AD6630 is an IF gain block designed to interface between SAW filters and differential input analog-to-digital converters. The AD

AD6630 Application

• Applications ADC IF Drive Amp Communications Receivers PCS/Cellular Base Stations GSM, CDMA, TDMA Differential, Low Noise IF Gain Block with Output
