ADG836L Datasheet, Mux, Analog Devices

ADG836L Features

• Mux 0.5 Ω typical on resistance 0.8 Ω maximum on resistance at 125°C 1.65 V to 3.6 V operation Automotive temperature range:
    –40°C to +125°C Guaranteed leakage specification

PDF File Details

Part number:

ADG836L

Manufacturer:

Analog Devices ↗

File Size:

303.48kb

Download:

📄 Datasheet

Description:

0.5 ohm cmos 1.65 v to 3.6 v dual spdt/2:1 mux. The ADG836L is a low voltage CMOS device containing two independently selectable single-pole, double-throw (SPDT) switches. This devi

ADG836L Application

• Applications Cellular phones PDAs MP3 players Power routing Battery-powered systems PCMCIA cards Modems Audio and video signal routing Communication
