ADG904-R Datasheet, Mux/sp4t, Analog Devices

ADG904-R Features

• Mux/sp4t Wideband switch:
    –3 dB @ 2.5 GHz ADG904: Absorptive 4:1 Mux/SP4T ADG904-R: Reflective 4:1 Mux/SP4T High off isolation (37 dB @ 1 GHz) Low insertion loss (1.1 dB dc to 1

PDF File Details

Part number:

ADG904-R

Manufacturer:

Analog Devices ↗

File Size:

336.76kb

Download:

📄 Datasheet

Description:

Wideband 37 db isolation at 1 ghz cmos 1.65v to 2.75v 4:1 mux/sp4t. The ADG904/ADG904-R are wideband analog 4:1multiplexers that use a CMOS process to provide high isolation and low insertion loss to 1

ADG904-R Application

• Applications Wireless communications General-purpose RF switching Dual-band applications High speed filter selection Digital transceiver front end s
