ADL5202 Datasheet, Vga, Analog Devices

ADL5202 Features

• Vga Dual independent, digitally controlled VGAs
• 11.5 dB to +20 dB gain range 0.5 dB ± 0.1 dB step size 150 Ω differential input and output 7.5 dB noise figure at maximum gain OIP3

PDF File Details

Part number:

ADL5202

Manufacturer:

Analog Devices ↗

File Size:

1.14MB

Download:

📄 Datasheet

Description:

Digitally controlled vga. The ADL5202 is a digitally controlled, variable gain, wide bandwidth amplifier that provides precise gain control, high output IP3, a

ADL5202 Application

• Applications Differential ADC drivers High IF sampling receivers High output power IF amplification Instrumentation GENERAL DESCRIPTION The ADL5202
