HMC700LP4E Datasheet, Pll, Analog Devices

HMC700LP4E Features

• Pll
• 8 GHz, 16 bit prescaler
• 24 bit step size resolution, 3 Hz typ
• Fractional or Integer Modes
• 200 MHz, 14bit reference path input

PDF File Details

Part number:

HMC700LP4E

Manufacturer:

Analog Devices ↗

File Size:

975.16kb

Download:

📄 Datasheet

Description:

8ghz 16-bit fractional-n pll. The HMC700LP4(E) is a SiGe BiCMOS fractional-N PLL. The PLL includes a very low noise digital phase frequency detector (PFD), and a p

HMC700LP4E Application

• Applications
• Base Stations for Mobile Radio
• WiMAX
• Test & Measurement
• CATV Equipment
• Phased A
