MAX16491 - Step-Down Switching Regulator

Product Overview

Analog Devices

Datasheet Details

Part number	MAX16491
Manufacturer	Analog Devices
File Size	3.43 MB
Description	Step-Down Switching Regulator
Datasheet	MAX16491 Datasheet
Additional preview pages of the MAX16491 datasheet.

Product details

Description

The MAX16491 is a fully integrated, highly efficient switching regulator for applications operating from 4.5V to 16V input supplies that require up to 9A maximum load.

Features

include: internal/external reference voltage, output voltage set-point, switching frequency, overcurrentprotection level (OCP), and soft-start timing. Discontinuous current mode (DCM) operation can be enabled using pin-strapping to improve light-load efficiency. The MAX16491 includes multiple protection and measurement features. Positive and negative cycle-by-cycle OCP, short-circuit protection and overtemperature protection (OTP) ensure robust design. Input undervoltage and overvoltage lockout.
