BP2832A - Non-isolated Buck Offline LED Driver

BP2832A Description

BP2832A Non-isolated Buck Offline LED Driver .
The BP2832A is a high precision buck constant current LED driver.

BP2832A Features

* Critical Conduction Mode Operation
* Internal 500V Power MOSFET
* No Auxiliary Winding
* Ultra Low Operating Current
* ±5% LED Output Current Accuracy
* LED Open Protection
* LED Short Protection
* Current Sensing Resistor Short Protection
* VCC Under Voltage Pr

BP2832A Applications

* LED Candle Light
* LED Bulb
* Other LED Lighting Typical Application AC BP2832A 4 VCC DRAIN 5 2 ROVP DRAIN 6 3 NC CS 7 1 GND CS 8 BP2832A_EN _DS_Rev.1.0 Figure 1. Typical application circuit for BP2832A www. bpsemi. com BPS Confidential
* Customer Use Only 1 Ordering

📥 Download Datasheet

Preview of BP2832A PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
BP2832A
Manufacturer
BPS
File Size
392.39 KB
Datasheet
BP2832A-BPS.pdf
Description
Non-isolated Buck Offline LED Driver
