DAC2904 Datasheet, Converter, Burr-Brown

DAC2904 Features

• Converter q 125MSPS UPDATE RATE q SINGLE SUPPLY: +3.3V or +5V www.DataSheet4U.com q HIGH SFDR: 78dB at fOUT = 10MHz q LOW GLITCH: 2pVs q LOW POWER: 310mW q INTERNAL REFERENCE q POWER-DOWN MODE: 2

PDF File Details

Part number:

DAC2904

Manufacturer:

Burr-Brown

File Size:

497.56kb

Download:

📄 Datasheet

Description:

125msps digital-to-analog converter. The DAC2904 is a monolithic, 14-bit, dual-channel, high-speed Digital-to-Analog Converter (DAC), and is optimized to provide high dyn

DAC2904 Application

• Applications q COMMUNICATIONS: Base Stations, WLL, WLAN Baseband I/Q Modulation q MEDICAL/TEST INSTRUMENTATION q ARBITRARY WAVEFORM GENERATORS (ARB)
