UPG2015TB Datasheet, Switch, CEL

UPG2015TB Features

• Switch
• SUPPLY VOLTAGE: VDD = 2.7 to 3.0 V (2.8 V TYP.)
• SINGLE SWITCH CONTROL VOLTAGE: Vcont (H) = 2.7 to 3.0 V (2.8 V TYP.) Vcont (L) =
• 0.2 to +0.2 V (0 V TYP.)

PDF File Details

Part number:

UPG2015TB

Manufacturer:

CEL

File Size:

156.53kb

Download:

📄 Datasheet

Description:

1w single control l / s-band spdt switch. NEC's UPG2015TB is a single control GaAs MMIC L, S-band SPDT (Single Pole Double Throw) switch for mobile phone and L, S-band applica

UPG2015TB Application

• Applications This device can operate frequency from 0.5 to 2.5 GHz, with low insertion loss and high isolation. This device is housed in a 6-pin su
