DW-AD-523-M12 Inductive proximity switch

data sheet Induktiver Näherungsschalter Détecteur de proximité inductif Inductive proximity switch DW - A - 52 Durchmesser Diamètre Diameter - M12 Schaltabstand Portée Operating distance M12 8 mm Einbau Montage Mounting quasi-bündig quasi-noyable quasi-embeddable Geräte mit sehr grossem Schaltabstand Wichtigste Eigenschaften: Schaltabstand 8 mm Betriebsspannung 1030 VDC, Ausgangsstrom 200 mA LED, Kurzschlussschutz, Induktionsschutz, Verpolungsschutz eingebaut.

DW-AD-523-M12 Features

* Operating distance 8 mm

* Supply voltage 10 30 VDC, output current 200 mA

* LED, protections against short-circuits, induced overvoltages and power supply reversal built-in

* Disponibles en PNP, NPN, à fermeture

* PNP and NPN, N.O. and N.C. et à ouverture

DW-AD-521-M12-CONTRINEX.pdf

DW-AD-523-M12 Datasheet Preview — This datasheet PDF includes multiple part numbers: DW-AD-523-M12, DW-AD-521-M12. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

DW-AD-523-M12, DW-AD-521-M12

Manufacturer:

CONTRINEX

File Size:

154.84 KB

Description:

Inductive proximity switch.

Note:

This datasheet PDF includes multiple part numbers: DW-AD-523-M12, DW-AD-521-M12.
Please refer to the document for exact specifications by model.
