DW-AD-524-M12, DW-AD-521-M12 - Inductive proximity switch

CONTRINEX

📥 Download Datasheet

DW-AD-524-M12 Datasheet Preview — This datasheet PDF includes multiple part numbers: DW-AD-524-M12, DW-AD-521-M12. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

Datasheet Details

Part number	DW-AD-524-M12, DW-AD-521-M12
Manufacturer	CONTRINEX
File Size	154.84 KB
Description	Inductive proximity switch
Datasheet	DW-AD-521-M12-CONTRINEX.pdf
Note	This datasheet PDF includes multiple part numbers: DW-AD-524-M12, DW-AD-521-M12. Please refer to the document for exact specifications by model.

DW-AD-524-M12 Product details

Features

Operating distance 8 mm.
Supply voltage 10 30 VDC, output current 200 mA.
LED, protections against short-circuits, induced overvoltages and power supply reversal built-in.
Disponibles en PNP, NPN, à fermeture.
PNP and NPN, N. O. and N. C. et à ouverture executions.
Raccordement par câble ou par connecteur S12 Technische Daten: (gemäss IEC 60947-5-2) Bemessungsschaltabstand s n Hysterese Normmessplatte Wiederholgenauigkeit Betriebsspannungs.
