TX1117 Datasheet - ChipSourceTek

TX1117 - 1A Bipolar LinearRegulator

TX1117 Features

* l Maximum output current is 1A l Range of operation input voltage: Max 12V l Line regulation: 0.1%/V (typ.) 1A Bipolar LinearRegulator l Standby current: 2mA (typ.) l Load regulation: 10mV (typ.) l Environment Temperature: -20 C~85 C Applications l Power Management for Computer Mother Board, Graph

TX1117-ChipSourceTek.pdf

Preview of TX1117 PDF
TX1117 Datasheet Preview Page 2 TX1117 Datasheet Preview Page 3

Datasheet Details

Part number:

TX1117

Manufacturer:

ChipSourceTek

File Size:

536.71 KB

Description:

1a bipolar linearregulator.
