Part number: CA-IF1021LD-Q1
Manufacturer: Chipanalog
File Size: 0.96MB
Download: 📄 Datasheet
Description: Automotive LIN Transceiver
* Meets LIN2.0、LIN2.1、LIN2.2、LIN2.2A and ISO 17987-4:2016(12V) Physical-layer (EPL) Standards
* Compliant to SAE J2602-1 and SAE J2602-2 LIN Physical-layer Specif.
with Wide Operating Supply Range:
* 5.5V to 27V supply range (VBAT)
* 3.3V and 5.0V Input Logic Compatible
*.
The CA-IF1021Lx-Q1 family of device is Local Interconnect Network (LIN) transceiver with integrated wake-up and protection features for automotive applications. LIN is lowspeed universal asynchronous receiver transmitter (UART) communication protocol.
