Description
cosmo z .
The KT1000 series consist of an infrared emitting diode, optically coupled to a phototransistor detector, and is incorporated in a 4 pin LSOP wide bod.
Features
* a high current transfer ratio, low coupling capacitance and high isolation voltage. KT1000 Series
4PIN LSOP PHOTOTRANSISTOR PHOTOCOUPLER
z Schematic 1
4
23
z Features
1. Halogen free 2. Pb free and RoHS compliant 3. High isolation voltage 5000Vrms 4. Opaque type, SMD low profile 4 lead package
Applications
* Hybrid substrates that require high density mounting.
* Programmable controllers.
* Switch mode power su
