CYUSB2025, CYUSB2024 - USB and Mass Storage Peripheral Controller

Cypress Semiconductor

📥 Download Datasheet

CYUSB2025 Datasheet Preview — This datasheet PDF includes multiple part numbers: CYUSB2025, CYUSB2024. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	CYUSB2025, CYUSB2024
Manufacturer	Cypress Semiconductor
File Size	396.16 KB
Description	USB and Mass Storage Peripheral Controller
Datasheet	CYUSB2024-CypressSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: CYUSB2025, CYUSB2024. Please refer to the document for exact specifications by model.

CYUSB2025 Product details

Features

Latest-generation storage support.
SD2.0/SDXC.
UHS1 SDR50 / DDR50 Master.
eMMC 4.4 Master.
SDIO 3.0 Master.
USB integration.
Certified USB 2.0 peripheral: Hi-Speed (HS), and Full-Speed (FS) only).
Thirty-two physical endpoints.
Integrated transceiver.
Accessory charger adaptor (ACA) support.
Ultra low-power in core power-down mode.
Less than 60 µA with VBATT on and 20 µA with VBATT off.
I2C master controller at 1 MHz.
Se.
