MMB158W, MMB1505W - (MMB1505W - MMB1510W) TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER

Name: MMB158W
SKU: MMB158W-595804

Dc Components

The MMB158W by Dc Components is a (MMB1505W - MMB1510W) TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER. Below is the official datasheet preview.

📥 Download Datasheet

MMB158W (MMB1505W - MMB1510W) TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER by Dc Components - Datasheet Preview — Official preview page of the **MMB158W** (MMB1505W - MMB1510W) TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER datasheet (Dc Components).

Datasheet Details

Part number	MMB158W, MMB1505W
Manufacturer	Dc Components
File Size	290.25 KB
Description	(MMB1505W - MMB1510W) TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER
Datasheet	MMB1505W_DcComponents.pdf
Note	This datasheet PDF includes multiple part numbers: MMB158W, MMB1505W. Please refer to the document for exact specifications by model.
Additional preview pages of the MMB158W datasheet.

MMB158W Product details

Features

Metal case for Maximum Heat Dissipation.
Diffused Junction.
High current capability.
Surge overload ratings - 300 Amperes.
Low forward voltage drop.
High Reliability .500 (12.7) TYP. .310(7.9) .290(7.4) .591 MAX. (15.0) MMB-25W.
