DA14583

Bluetooth Low Energy 4.2 SoC

DA14583 General Description


* Memories The DA14583 integrated circuit has a fully integrated radio transceiver and baseband processor for Bluetooth® Smart. It can be used as a standalone application processor or as a data pump in hosted systems.
* 1 Mbit Flash memory
* 32 kB One-Time-Programmable (OTP) memory

DA14583 Datasheet (2.41 MB)

Preview of DA14583 PDF

Datasheet Details

Part number:

DA14583

Manufacturer:

Dialog Semiconductor

File Size:

2.41 MB

Description:

Bluetooth low energy 4.2 soc.
