DA14581

Bluetooth Low Energy 4.2 SoC

DA14581 Features

* Supply current at VBAT3V: TX: 3.4 mA, RX: 3.7 mA (with ideal DC-DC)

* Complies with Bluetooth V4.2, ETSI EN 300 328 and

* 0 dBm transmit output power N EN 300 440 Class 2 (Europe), FCC CFR47 Part 15

* -20 dBm output power in “Near Field Mode” (US) and ARIB STD-T66 (Japan)

DA14581 General Description


* AES-128 bit encryption Processor The DA14581 integrated circuit is an optimized version of the DA14580, offering a reduced boot time and supporting up to 8 connections. It has a fully integrated radio transceiver and baseband processor for Bluetooth® low energy. It can be used as a standalon.

DA14581 Datasheet (3.36 MB)

Preview of DA14581 PDF

Datasheet Details

Part number:

DA14581

Manufacturer:

Renesas ↗

File Size:

3.36 MB

Description:

Bluetooth low energy 4.2 soc.
