DMT5015LFDF

N-Channel MOSFET

DMT5015LFDF Features

* 0.6mm Profile

* Ideal for Low Profile Applications

* PCB Footprint of 4mm2

* Low Gate Threshold Voltage

* Fast Switching Speed

* Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

* Halogen and Antimony Free. “Green” Device (Note 3)

* For automotive applicat

DMT5015LFDF General Description

and Applications This MOSFET is designed to minimize the on-state resistance (RDS(ON)) yet maintain superior switching performance, making it ideal for high-efficiency power management applications.
* Load Switch
* Adaptor Switch
* Notebook PC Mechanical Data
* Case: U-DFN2020-6 (Ty.

DMT5015LFDF Datasheet (670.30 KB)

Preview of DMT5015LFDF PDF

Datasheet Details

Part number:

DMT5015LFDF

Manufacturer:

DIODES ↗

File Size:

670.30 KB

Description:

N-channel mosfet.
NOT RECOMMENDED FOR NEW DESIGN CONTACT US DMT5015LFDF 50V N-CHANNEL ENHANCEMENT MODE MOSFET Product Summary V(BR)DSS 50V RDS(ON) Max 15mΩ @ VGS =.
