FP1005R - High current power inductors

Description

High current carrying capacity Low core loss Magnetically shielded Frequency range up to 2 MHz Inductance range 85 nH to 220 nH Current range 33 A to 90 A 10.2 mm x 7.0 mm footprint surface mount package in a 4.95 mm height

EATON

📥 Download Datasheet

Datasheet Details

Part number	FP1005R
Manufacturer	EATON
File Size	434.96 KB
Description	High current power inductors
Datasheet	FP1005R Datasheet
