HTS28S24

High-reliability hybrid integrated DC/DC converter

HTS28S24 Features

* (see Fig. 1 for outside view, and Table 1 for models) Range of input DC voltage: 18~36V, nominal input DC voltage 28V Output power: 45W Operating temperature (Tc): -55~+105 Input, output and case are isolated mutually Insulation resistance: R≥100MΩ(DC 500V)  With the function of inhibit and short-ci

HTS28S24 General Description

HTW28 series high-reliability DC/DC converter can work at 28V input voltage, and the output power is 45W.The case of this series is of totally sealed metal structure with fixed end or without fixed end. HTW28 series products adopt push-pull structure, both the design and manufacture of HSG28 series .

HTS28S24 Datasheet (1.50 MB)

Preview of HTS28S24 PDF

Datasheet Details

Part number:

HTS28S24

Manufacturer:

ECRIM

File Size:

1.50 MB

Description:

High-reliability hybrid integrated dc/dc converter.
