STU6xxx, STU6010 SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

EIC discrete Semiconductors

Description

STU606I - STU65G4 VBR : 6.8 - 440 Volts PPK : 600 Watts .

📥 Download Datasheet

STU6xxx Datasheet Preview — This datasheet PDF includes multiple part numbers: STU6xxx, STU6010. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: STU6xxx, STU6010
Manufacturer: EIC discrete Semiconductors
File Size: 63.77 KB
Datasheet: STU6010_EICdiscreteSemiconductors.pdf
Description: SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
Note: This datasheet PDF includes multiple part numbers: STU6xxx, STU6010.
Please refer to the document for exact specifications by model.

Features

* : www. DataSheet4U. com
* 600W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR SMB (DO-214AA) 1.1 ± 0.3 5.4 ± 0.15 surge capability at 1ms
* Excellent clamping capability
* Low zener impedance
* Fast response time : typically less then 1.0 ps from 0 volt to VBR(min. )
* Typical IR les

Applications

* For bi-directional altered the third letter of type from "U" to be "B". Electrical characteristics apply in both directions MAXIMUM RATINGS Rating at 25 °C ambient temperature unless otherwise specified. Rating Peak Power Dissipation at Ta = 25 °C, Tp=1ms (Note1) Steady State Power Dissipation at
