ESS9012, ESS9018 Datasheet - ESS

ESS9012 Reference 32-bit Audio DAC

Package DNR (dB) THD (dB) 32-bit I2S/DSD SPDIF Jitter Number ES9018 SABRE32 Reference 64-LQFP 135 (mono) -120 DAC Yes Input Yes Input Reduction Yes Yes 8-Channel Audio DAC 129 (8ch) ES9012 SABRE32 Reference 64-LQFP 135 (mono) -120 Yes Yes Yes Yes Stereo Audio DAC 133 (2ch) With ESS p.

ESS9012 Features

* Feature Patented 32-bit Hyperstream DAC o Up to 135dB DNR o -120dB THD+N Patented Time Domain Jitter Eliminator Universal digital input for up to 1.536MHz1 sampling rate Integrated DSP functions Customizable output configuration Customizable filter characteristics 100mW power consumption Benefit

ESS9018-ESS.pdf

This datasheet PDF includes multiple part numbers: ESS9012, ESS9018. Please refer to the document for exact specifications by model.
ESS9012 Datasheet Preview Page 2 ESS9012 Datasheet Preview Page 3

Datasheet Details

Part number:

ESS9012, ESS9018

Manufacturer:

ESS

File Size:

706.13 KB

Description:

Reference 32-bit audio dac.

Note:

This datasheet PDF includes multiple part numbers: ESS9012, ESS9018.
Please refer to the document for exact specifications by model.
