ESS9018 - Reference 32-bit Audio DAC

ESS

ESS9018 Datasheet Preview — Preview of ESS9018 PDF

Datasheet Details

Part number	ESS9018
Manufacturer	ESS
File Size	706.13 KB
Description	Reference 32-bit Audio DAC
Datasheet	ESS9018-ESS.pdf

ESS9018 Product details

Description

Package DNR (dB) THD (dB) 32-bit I2S/DSD SPDIF Jitter Number ES9018 SABRE32 Reference 64-LQFP 135 (mono) -120 DAC Yes Input Yes Input Reduction Yes Yes 8-Channel Audio DAC 129 (8ch) ES9012 SABRE32 Reference 64-LQFP 135 (mono) -120 Yes Yes Yes Yes Stereo Audio DAC 133 (2ch) With ESS patented 32-bit Hyperstream DAC architecture and Time Domain Jitter Eliminator, the SABRE32 Reference Stereo DAC delivers an unprecedented DNR of up to 135dB and THD+N of -120dB, the industry’s highes

Features

Feature Patented 32-bit Hyperstream DAC o Up to 135dB DNR o -120dB THD+N Patented Time Domain Jitter Eliminator Universal digital input for up to 1.536MHz1 sampling rate Integrated DSP functions Customizable output configuration Customizable filter characteristics 100mW power consumption Benefit Industry’s highest performance 32-bit audio DAC with unprecedented dynamic range and ultra low distortion Unmatched audio clarity free from input clock jitter Supports SPDIF, PCM (I2S, MSB/LSB justifi.
