EDI88128LP Datasheet - ETC

EDI88128LP - 128K X 8 STATIC RAM CMOS MONOLITHIC

EDI88128C 128KX8 MONOLITHIC SRAM, SMD 5962-89598 n Access Times of 70, 85, 100ns n Available with Single Chip Selects (EDI88128) or Dual Chip Selects (EDI88130) n 2V Data Retention (LP Versions) n CS and OE Functions for Bus Control n TTL Compatible Inputs and Outputs n Fully Static, No Clocks n Organized as 128Kx8 n Industrial, Military and Commercial Temperature Ranges n Thru-hole and Surface Mount Packages JEDEC Pinout 32 pin Ceramic DIP, 0.6 mils wide (Package 9) 32 lead

EDI88128LP Features

* The EDI88128C is a high speed, high performance, Monolithic CMOS Static RAM organized as 128Kx8. The device is also available as EDI88130C with an additional chip select line (CS2) which will automatically power down the device when proper logic levels are applied. The second chip select line (CS2)

EDI88128LP_ETC.pdf

Preview of EDI88128LP PDF
EDI88128LP Datasheet Preview Page 2 EDI88128LP Datasheet Preview Page 3

Datasheet Details

Part number:

EDI88128LP

Manufacturer:

ETC

File Size:

153.47 KB

Description:

128k x 8 static ram cmos monolithic.
