‧High current capability ‧High surge current capability ‧Low reverse current ‧Component in accordance to RoHS 2002/95/EC
Primary Characteristics
IF 5
VRRM
50~1300
IFSM
125
VF 1.15
TJ max
150
A V A V °C
Mechanical Data
‧Cases: DO-214AB(SMC) ‧Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0 ‧Terminals: Lead free Plating (Tin Finish)
Solderable per MIL-STD-202, Method 208 ‧Polarity: Cathode Band ‧Weight: 0.231 grams (approximate)
Ordering Information
Part No.
