EUP3412 Datasheet, Converter, Eutech Microelectronics

EUP3412 Features

• Converter High Efficiency up to 96% 1.5A Available Load Current 300µA Typical Quiescent Current 1.5MHz Constant Switching Frequency 2.7V to 5.5V Input Voltage Range Adjustable Output Voltage as L

PDF File Details

Part number:

EUP3412

Manufacturer:

Eutech Microelectronics

File Size:

464.00kb

Download:

📄 Datasheet

Description:

Synchronous step-down converter. The EUP3412 is a synchronous current mode step-down dc-dc converter, capable of driving 1.5A load current with excellent line and loa

EUP3412 Application

• Applications powered by a single Li-Ion battery cell or by 3-cell NiMH/NiCd batteries. The EUP3412 operates at a fixed switching frequency of 1.5MHz
