EL3020 6PIN DIP RANDOM-PHASE TRIAC DRIVER PHOTO COUPLER

The EL301X, EL302X and EL305X series of devices each consist of a GaAs infrared emitting diode optically coupled to a monolithic silicon random phase photo Triac. They are designed for interfacing between electronic controls and power triacs to control resistive and inductive loads for 115 to 240 V.

EL3020 Features

* Peak breakdown voltage - 250V: EL301X - 400V: EL302X - 600V: EL305X

* High isolation voltage between input and output (Viso=5000 V rms )

* Compact dual-in-line package

* Compliance with EU REACH

* The product itself will remain within RoHS compliant version

EL3020 Datasheet (1.63 MB)

EL3020 Datasheet Preview — Preview of EL3020 PDF
