MP7611 Datasheet - Exar Corporation

MP7611 Octal 14-Bit DAC Array D/A Converter

The MP7611 provides eight independent 14-bit resolution Digital-to-Analog Converters with voltage output amplifiers and a parallel digital address and data port. Built using an advanced linear BiCMOS, these devices offer rugged solutions that are latch-up free, and take advantage of EXAR’s patente.

MP7611 Features

* MP7611 Octal 14-Bit DAC ArrayTM D/A Converter with Output Amplifier and Parallel Data/Address mP Control Logic June 1998-3

* Eight Independent Channel 14-Bit DACs with Output Amplifiers

* Low Power 320 mW (typ.)

* Parallel Digital Data and Address Port

* Double Buffered Data Interf

MP7611_ExarCorporation.pdf

MP7611 Datasheet Preview — Preview of MP7611 PDF

Datasheet Details

Part number:

MP7611

Manufacturer:

Exar Corporation

File Size:

531.63 KB

Description:

Octal 14-bit dac array d/a converter.
