MP7612 - Octal 12-Bit DAC Array D/A Converter

Name: MP7612
SKU: MP7612-536349

Exar Corporation

📥 Download Datasheet

MP7612 Datasheet Preview — Preview of MP7612 PDF

Datasheet Details

Part number	MP7612
Manufacturer	Exar Corporation
File Size	190.35 KB
Description	Octal 12-Bit DAC Array D/A Converter
Datasheet	MP7612_ExarCorporation.pdf

MP7612 Product details

Description

The MP7612 provides eight independent 12-bit resolution Digital-to-Analog Converters with voltage output amplifiers and a 3-wire standard serial digital address and data port. + LD 12 t a 8 S a e h D Q sinking and sourcing 5mA, an

Features

w.
Eight Independent 12-Bit DACs with Output Amplifiers.
Low Power 320 mW (typ. ).
Serial Digital Data and Address Port (3-Wire Standard).
12-Bit Resolution, 11 Bit Accuracy.
Extremely Well Matched DACs.
Extremely Low Analog Ground Current (.
