1N5401GP, 1N5400GP 3 Amp. Glass Passivated Junction Rectifier

FAGOR

Description

1N5400GP 1N5408GP 3.0 Amp.Glass Passivated Junction Rectifier DO-201AD (DO-27) Voltage 50V to 1000 V Current 3.0 A at 105º C R .

📥 Download Datasheet

1N5401GP Datasheet Preview — This datasheet PDF includes multiple part numbers: 1N5401GP, 1N5400GP. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: 1N5401GP, 1N5400GP
Manufacturer: FAGOR
File Size: 291.01 KB
Datasheet: 1N5400GP-FAGOR.pdf
Description: 3 Amp. Glass Passivated Junction Rectifier
Note: This datasheet PDF includes multiple part numbers: 1N5401GP, 1N5400GP.
Please refer to the document for exact specifications by model.

Features

* Glass passivated chip junction Hyperectifier structure for high reliability Cavity-free glass-passivated junction Low forward voltage drop Low leakage current, typical IR less than 0.1 µA High forward surge capability Solder dip 260ºC, 10s Component in accordance to RoHS 2011/65/EU a

Applications

* Used in general purpose rectification of power supplies, inverters, converters and freewheeling diodes application Maximun Ratings and Electrical Characteristics at 25°C VRRM IF(AV) IFRM IFSM Tj T
