DM74LS469 Datasheet, Counter, Fairchild Semiconductor

DM74LS469 Features

• Counter Benefits n 8-bit up/down counter for microprogram-counter, DMA controller and general-purpose counting applications n 8 bits matches byte boundaries n Bus-structured pinout n 24-pin SKI

PDF File Details

Part number:

DM74LS469

Manufacturer:

Fairchild Semiconductor

File Size:

143.35kb

Download:

📄 Datasheet

Description:

8-bit up/down counter. The ’LS469 is an 8-bit synchronous up/down counter with parallel load and hold capability. Three function-select inputs (LD, UD, CBI)

DM74LS469 Application

• Applications n 8 bits matches byte boundaries n Bus-structured pinout n 24-pin SKINNYDIP saves space n 3-STATE outputs drive bus lines n Low current
