QTLP611C-EB Datasheet, Angle, Fairchild Semiconductor

QTLP611C-EB Features

• Angle
• Miniature footprint - 2.1(L) X 1.0(W) X 0.6(H) mm
• Wide viewing angle of 130°
• Water clear optics
• Available in 0.315" (8mm) width tape on 7" (178mm

PDF File Details

Part number:

QTLP611C-EB

Manufacturer:

Fairchild Semiconductor

File Size:

364.56kb

Download:

📄 Datasheet

Description:

Surface mount led lamp compact right angle. This compact right angle surface mount chip LED emits light in the lateral direction. Miniature size and wide viewing angle make this

QTLP611C-EB Application

• Applications
• LCD edge-lighting
• Edge card lighting NOTE: Dimensions for all drawings are in inches (mm). Description This compa
