NC7SZ157 - TinyLogic UHS 2-Input Non-Inverting Multiplexer

Datasheet Summary

Description

The NC7SZ157 is a single, high performance, 2 to 1 CMOS non-inverting multiplexer from Fairchild’s Ultra High Speed Series of TinyLogic.

Features

  • s Space saving SC70-6 lead surface mount package s Ultra Small MicroPak leadless package s Ultra High Speed s Broad VCC operating range: 1.65V to 5.5V s Power down high impedance input/output s Overvoltage tolerant inputs facilitate 5V to 3V translation s Patented noise/EMI reduction circuitry implemented Ordering Code: Order Number NC7SZ157P6X NC7SZ157L6X Package Number MAA06A MAC06A Package Top Mark ZF7 B9 Package.

📥 Download Datasheet

Datasheet preview – NC7SZ157

Datasheet Details

Part number NC7SZ157
Manufacturer Fairchild
File Size 113.18 KB
Description TinyLogic UHS 2-Input Non-Inverting Multiplexer
Datasheet download datasheet NC7SZ157 Datasheet
