FT6264 Datasheet - Force Technologies

ULTRA HIGH SPEED 8K x 8 STATIC CMOS RAMS

FT6264 Features

* Full CMOS, 6T Cell High Speed (Equal Access and Cycle Times)

* 8/10/12/15/20/25/35/70/100 ns (Commercial)

* 10/12/15/20/25/35/70/100 ns(Industrial)

* 12/15/20/25/35/45/70/100 ns (Military) Low Power Operation Output Enable and Dual Chip Enable Control Functions Single 5V±10%

FT6264 General Description

The FT6264 is a 65,536-bit ultra high-speed static RAM organised as 8K x 8. The CMOS memory requires no clocks or refreshing and has equal access and cycle times. Inputs are fully TTL-compatible. The RAM operates from a single 5V±10% tolerance power supply. With battery backup, data integrity is mai.

FT6264 Datasheet (743.99 KB)

FT6264 Datasheet Preview — Preview of FT6264 PDF

Datasheet Details

Part number:

FT6264

Manufacturer:

Force Technologies

File Size:

743.99 KB

Description:

Ultra high speed 8k x 8 static cmos rams.
