FT6264L - ULTRA HIGH SPEED 8K x 8 STATIC CMOS RAMS

Product Overview

📥 Download Datasheet

FT6264L ULTRA HIGH SPEED 8K x 8 STATIC CMOS RAMS by Force Technologies - Datasheet Preview — Datasheet preview – FT6264L

Datasheet Details

Part number	FT6264L
Manufacturer	Force Technologies
File Size	743.99 KB
Description	ULTRA HIGH SPEED 8K x 8 STATIC CMOS RAMS
Datasheet	FT6264L Datasheet
Note	This datasheet PDF includes multiple part numbers: FT6264L, FT6264. Please refer to the document for exact specifications by model.
Additional preview pages of the FT6264L datasheet.

Product details

Description

The FT6264 is a 65,536-bit ultra high-speed static RAM organised as 8K x 8.

Features

Full CMOS, 6T Cell High Speed (Equal Access and Cycle Times).
8/10/12/15/20/25/35/70/100 ns (Commercial).
10/12/15/20/25/35/70/100 ns(Industrial).
12/15/20/25/35/45/70/100 ns (Military) Low Power Operation Output Enable and Dual Chip Enable Control Functions Single 5V±10% Power Supply Data Retention with 2.0V Supply, 10 µA Typical Current (FT6264L Military).
