MC9S08SE8 - Microcontrollers

Product Overview

Freescale Semiconductor

Datasheet Details

Part number	MC9S08SE8
Manufacturer	Freescale Semiconductor
File Size	3.69 MB
Description	Microcontrollers
Datasheet	MC9S08SE8 Datasheet
Additional preview pages of the MC9S08SE8 datasheet.

Product details

Description

of Changes Initial public released.Changed the MCG at 0xFFAF in Table 4-4 to ICS.Modified some typos.Updated Figure 4-2 and Figure 4-3. In Chapter 10, “Internal Clock Source (S08ICSV3),” added a note in Section 10.1.4.7, “Stop (STOP);” updated Figure 10-2 to reflect ICSERCLK is gated off when STOP is high or when ERCLKEN is low.This product incorporates SuperFlash® technology licensed from SST.Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc.© Freescale Semi

Features

8-Bit HCS08 Central Processor Unit (CPU).
20 MHz HCS08 CPU (central processor unit).
10 MHz internal bus frequency.
HC08 instruction set with added BGND.
Support for up to 32 interrupt/reset sources On-Chip Memory.
Up to 8 KB of on-chip in-circuit programmable flash memory with block protection and security options.
Up to 512 bytes of on-chip RAM Power-Saving Modes Clock Source Options.
Oscillator (XOSC).
Loop-control Pierce.
