MC9S08SH16 - HCS08 Microcontroller

Product Overview

Freescale Semiconductor

Datasheet Details

Part number	MC9S08SH16
Manufacturer	Freescale Semiconductor
File Size	2.23 MB
Description	HCS08 Microcontroller
Datasheet	MC9S08SH16 Datasheet
Additional preview pages of the MC9S08SH16 datasheet.

Product details

Description

of Changes Updated The ACMP and TPM modules to version 3 and made numerous revisions to the Electricals.Updated device numbering scheme.Updated some electricals and made some minor grammatical/formatting revisions.Corrected the SPI block module version.Removed incorrect ADC temperature sensor value from the

Features

8-Bit HCS08 Central Processor Unit (CPU).
40-MHz HCS08 CPU (central processor unit).
HC08 instruction set with added BGND instruction.
Support for up to 32 interrupt/reset sources On-Chip Memory.
FLASH read/program/erase over full operating voltage and temperature.
Random-access memory (RAM).
Security circuitry to prevent unauthorized access to RAM and FLASH contents Power-Saving Modes.
Two very low power stop modes.
Reduce.
