FQD4N60C - 4A 600V N-Channel MOSFET

FQD4N60C Description

4A, 600V, N H FQU4N60C FQD4N60C H4N60U H4N60D 4N60 HAOHAI U: TO-251 D: TO-252 4N60 Series N-Channel MOSFET 80/ 2.5K/ 4Kpc.

FQD4N60C Features

* 　　LOW ON-RESISTANCE 　　FAST SWITCHING 　　HIGH INPUT RESISTANCE 　　RoHS COMPLIANT 　　Package: TO-251 or TO-252（IPAK & DPAK） ID=4A VDS=600V RDS(on)=2.5Ω 　
* 　　、、、RoHS 　
* 　　、LCD、LED、、UPS 　　、、、、 　　、、 　　、 　
* 　　TO-251（IPAK）、TO-252（DPAK） 4N60 Series Pin Assignment 3-Lead Plastic TO-251 Package

📥 Download Datasheet

Preview of FQD4N60C PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
FQD4N60C
Manufacturer
HAOHAI
File Size
355.75 KB
Datasheet
FQD4N60C-HAOHAI.pdf
Description
4A 600V N-Channel MOSFET
