SS443 Datasheet - HONEYWELL

Hall-effect Digital Position Sensor

SS443 Features

* Quad Hall IC design minimizes mechanical stress effects

* Temperature-compensated magnetics help provide stable operation over a wide temperature range of -40°C to 150°C [-40°F to 302°F]

* Broad, inclusive supply voltage capability from 3.8 Vdc to 30 Vdc for application fle

SS443 General Description

The SS400 Series and SS500 Series are small and versatile digital Hall-effect devices that are operated by the magnetic field from a permanent magnet or an electromagnet, and are designed to respond to alternating North and South poles, or to a South pole only. They are available in bipolar, latchin.

SS443 Datasheet (1.27 MB)

SS443 Datasheet Preview — Preview of SS443 PDF

Datasheet Details

Part number:

SS443

Manufacturer:

HONEYWELL

File Size:

1.27 MB

Description:

Hall-effect digital position sensor.
