HD66106F Datasheet, Driver, Hitachi

HD66106F Features

• Driver
• Column and row driver
• 80 LCD drive circuits
• Multiplexing duty ratios: 1/100 to 1/480
• 4-bit parallel data transfer
• Internal automatic ch

PDF File Details

Part number:

HD66106F

Manufacturer:

Hitachi

File Size:

87.67kb

Download:

📄 Datasheet

Description:

Lcd driver. The HD66106F LCD driver has a high duty ratio and many outputs for driving a large capacity dot matrix LCD panel. It includes 80 LCD
