SS143A - (SS100 Series) Surface Mount Digital Position Sensors

This page provides the datasheet information for the SS143A, a member of the SS141A (SS100 Series) Surface Mount Digital Position Sensors family.

Datasheet Summary

Features

  • ɀ Quad Hall design virtually eliminates mechanical stress effects ɀ Temperature compensated magnetics ɀ Bipolar, unipolar, latching magnetics ɀ Super high sensitivity available ɀ Symmetry of operate/release points about zero gauss (bipolar/latching) ɀ Operating temperature range of.
  • 40 to ⍣125°C ɀ Low current consumption (7 mA typical @ 5 V, 25°C) ɀ 3.8 to 30 VDC supply voltage range ɀ High output current capability of 50 mA absolute maximum ORDER GUIDE Catalog Listing Magnetic Type Sup.

📥 Download Datasheet

Datasheet preview – SS143A

Datasheet Details

Part number SS143A
Manufacturer Honeywell
File Size 253.44 KB
Description (SS100 Series) Surface Mount Digital Position Sensors
Datasheet download datasheet SS143A Datasheet
