IDT7054S - HIGH-SPEED 4K x 8 FourPort STATIC RAM

Datasheet Details

Part number	IDT7054S
Manufacturer	IDT
File Size	268.12 KB
Description	HIGH-SPEED 4K x 8 FourPort STATIC RAM
Datasheet	IDT7054S-IDT.pdf

The IDT7054 is a high-speed 4K x 8 FourPort™ Static RAM designed to be used in systems where multiple access into a common RAM is required.

High-speed access.
Commercial: 20/25/35ns (max. ).
Industrial: 25ns (max. ).
Low-power operation.
IDT7054S Active: 750mW (typ. ) Standby: 7.5mW (typ. ).
IDT7054L Active: 750mW (typ. ) Standby: 1.5mW (typ. ).
True FourPort memory cells which allow simultaneous access of the same memory locations.
Fully asynchronous operation from each of the four ports: P1, P2, P3, and P4.
TTL-compatible; single 5V (±10%) power supply.
Available in 128.
