IDT70T3589 Features
* True Dual-Port memory cells which allow simultaneous access of the same memory location
* High-speed data access
* Commercial: 3.4 (200MHz)/3.6ns (166MHz)/ 4.2ns (133MHz)(max.)
* Industrial: 3.6ns (166MHz)/4.2ns (133MHz) (max.)
* Selectable Pipelined or Flow-Through ou
Datasheet Details
IDT70T3589, IDT70T3519
IDT
397.79 KB
High-speed 2.5v 256/128/64k x 36 synchronous dual-port static ram.
This datasheet PDF includes multiple part numbers: IDT70T3589, IDT70T3519.
Please refer to the document for exact specifications by model.
