K1000MA600, Medium Voltage Thyristor

WESTCODE An IXYS Company Date:- 22 June, 2011 Data Sheet Issue:- P1 Prospectve Data Medium Voltage Thyristor Type K1000M#600 to K1000M#650 Development Type No.

KX283M#600-650 Absolute Maximum Ratings VDRM VDSM VRRM VRSM VOLTAGE RATINGS Repetitive peak off-state voltage, (note 1) Non-repetitive peak off-state voltage, (note 1) Repetitive peak reverse voltage, (note 1) Non-repetitive peak reverse voltage, (note 1) MAXIMUM LIMITS 6000-6500 6000-6500 6000-6500 6100-6600 UNITS V V V V OTHER RA
