2SB705A Datasheet, Transistor, Inchange Semiconductor

PDF File Details

Part number:

2SB705A

Manufacturer:

Inchange Semiconductor

File Size:

245.00kb

Download:

📄 Datasheet

Description:

Power transistor.

Collector-Emitter Breakdown Voltage: V(BR)CEO= -140V(Min)

Complement to Type 2SD745

High Power Dissipation

2SB705A Application

• Applications
• For audio frequency power amplifier applications
• Suitable for output stages of 60~120 watts audio amplifier and volta
